Fostex Multitracker X-12

Fostex Multitracker X-12; Foster Electric Co. (ID = 2379599) R-Player Fostex Multitracker X-12; Foster Electric Co. (ID = 2379600) R-Player
Fostex Multitracker X-12; Foster Electric Co. (ID = 2379601) R-Player Fostex Multitracker X-12; Foster Electric Co. (ID = 2379602) R-Player
Fostex Multitracker X-12; Foster Electric Co. (ID = 2379603) R-Player Fostex Multitracker X-12; Foster Electric Co. (ID = 2379604) R-Player
Fostex Multitracker X-12; Foster Electric Co. (ID = 2379605) R-Player
Use red slider bar for more.
Fostex Multitracker X-12; Foster Electric Co. (ID = 2379599) R-Player
Foster Electric Co.: Fostex Multitracker X-12 [R-Player] ID = 2379599 1400x892
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fostex Multitracker X-12, Foster Electric Co. Ltd. (Fostex); Tokyo

Country:  Japan
Manufacturer / Brand:  Foster Electric Co. Ltd. (Fostex); Tokyo
alternative name

Fostex Company
Year: 1984 ?? Category: Sound/Video Recorder and/or Player
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Powered by external power supply or a main unit. / 12 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Fostex Multitracker X-12 - Foster Electric Co. Ltd.
Material Plastics (no bakelite or catalin)
Shape Book-shelf unit.
Dimensions (WHD) 275 x 68 x 177 mm / 10.8 x 2.7 x 7 inch
Notes

Record Tracks : 4 tracks, one direction
Tape Speed : 4.76cm/s
Frequency Response
Mixer section : 20Hz ~ 20kHz
Recorder section : 40Hz ~ 10kHz
HEADS
Rec/Play : 4-track, 4-channel recording/playback
Erase : 4-track, 4-channel erase
INPUT
Connector (x1) : ø6mm PHONE jack
Input Impedance : 20kW or higher
Reference Input Level : -50dBV ~ -10dBV
(adjustable with the GAIN knob)
LINE OUT (L, R)
Connector (x2) : RCA pin jack
Output Load Impedance: 10kW or higher
Reference Output Level : -10dBV
PHONES
Connector (x1) : ø6mm STEREO
PHONE jack
Output Load Impedance: 16W or higher
Maximum Output : 10mW (at 32W)
Recording Tape : Less than C-90
(TYPE II/HIGH position)
Power Supply : Fostex AC Adaptor, AD-12A
DC12V (12 ~ 16V), 8W

Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)

Model page created by Bartosz Szwed. See "Data change" for further contributors.
