For model Line Mixer 2016, Foster Electric Co. Ltd. (Fostex); Tokyo

Country:  Japan
Manufacturer / Brand:  Foster Electric Co. Ltd. (Fostex); Tokyo
alternative name

Fostex Company
Year: 1989 ? Category: Miscellaneous (Other, Various) - see notes
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Line Mixer 2016 - Foster Electric Co. Ltd.
Material Metal case
Shape Rack
Dimensions (WHD) 482 x 92 x 185 mm / 19 x 3.6 x 7.3 inch
Notes

INPUTS

input (x16)  -10dBV 10kOhms
AUX RTN (Stereo) x2 -20dBV 10kOhms
Line buss (x4) -10dBV 50kOhms
AUX buss (x4) -10dBV 100kOhms

OUTPUTS

Line Out (stereo) x2 -10dBV 10kOhms
AUX out (x4) -10dBV 10kOhms

Frequency Response - 20Hz-20kHz
S/N 80dB
Distortion 0.01% (100Hz-10kHz)
Crosstalk 65dB (1kHz)




Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)

Model page created by Bartosz Szwed. See "Data change" for further contributors.
