Constant 6T-170

Constant 6T-170; Fuji High Frequency (ID = 1680299) Radio
Constant 6T-170; Fuji High Frequency (ID = 2424689) Radio Constant 6T-170; Fuji High Frequency (ID = 2424691) Radio
Constant 6T-170; Fuji High Frequency (ID = 2424690) Radio Constant 6T-170; Fuji High Frequency (ID = 2424692) Radio
Constant 6T-170; Fuji High Frequency (ID = 2424133) Radio Constant 6T-170; Fuji High Frequency (ID = 2424132) Radio
Constant 6T-170; Fuji High Frequency (ID = 2424134) Radio Constant 6T-170; Fuji High Frequency (ID = 2424135) Radio
Constant 6T-170; Fuji High Frequency (ID = 2424136) Radio
Use red slider bar for more.
Constant 6T-170; Fuji High Frequency (ID = 2424689) Radio
Fuji High Frequency: Constant 6T-170 [Radio] ID = 2424689 1400x1879
Select picture or schematic to display from thumbnails on the right and click for download.
For model Constant 6T-170, Fuji High Frequency Radio Lab. Co., LTD.; (where?)

Country:  Japan
Manufacturer / Brand:  Fuji High Frequency Radio Lab. Co., LTD.; (where?)
Brand

Constant
Year: 1959 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: 2NJ8 2NJ5 2NJ5 2NJ9 2NJ9 2NJ9
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 1 x 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Constant 6T-170 - Fuji High Frequency Radio Lab.
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 57 x 95 x 34 mm / 2.2 x 3.7 x 1.3 inch
Notes

Constant 6T-170;
Earphone jack, sea green colored.

Similar design to Minute Man 6T-170.

Net weight (2.2 lb = 1 kg) 0.170 kg / 0 lb 6 oz (0.374 lb)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Fuji High Frequency Radio Lab. Co., LTD.; (where?)
Here you find 12 models, 12 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
