677B

677B ; Gamble-Skogmo, Inc.; (ID = 371249) Car Radio

677B ; Gamble-Skogmo, Inc.; (ID = 371250) Car Radio
Use red slider bar for more.
677B ; Gamble-Skogmo, Inc.; (ID = 371249) Car Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Gamble-Skogmo, Inc.; Minneapolis, MN
Brand

Coronado
Year: 1939 ?? Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 6: 6K7 6A8 6K7 6Q7 6V6 0Z4 or 6X5
Main principle Superhet with RF-stage; ZF/IF 465 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6.3 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: 677B - Gamble-Skogmo, Inc.;
Notes Vibrator for +B.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before
