777C Ch= Series B

777C Ch= Series B; Gamble-Skogmo, Inc.; (ID = 372355) Radio

777C Ch= Series B; Gamble-Skogmo, Inc.; (ID = 372356) Radio

777C Ch= Series B; Gamble-Skogmo, Inc.; (ID = 372357) Radio
Use red slider bar for more.
777C Ch= Series B; Gamble-Skogmo, Inc.; (ID = 372355) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Gamble-Skogmo, Inc.; Minneapolis, MN
Brand

Coronado
Year: 1936 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6D6 6C6 6D6 76 6B7 42 80
Main principle Superhet with RF-stage; ZF/IF 465 kHz
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 110 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 777C Ch= Series B - Gamble-Skogmo, Inc.;
Circuit diagram reference Rider's Perpetual, Volume 7 = 1936 and before

Model page created by Dirk Taekels. See "Data change" for further contributors.
