AM FM Television Receiver 15TZ Series 15TZ6

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451379) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451381) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451382) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451383) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451385) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451386) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451388) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451389) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451391) TV Radio

AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1451392) TV Radio
AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1438220) TV Radio
Use red slider bar for more.
AM FM Television Receiver 15TZ Series 15TZ6; Garod Radio Corp.; (ID = 1438220) TV Radio
Garod Radio Corp.;: AM FM Television Receiver 15TZ Series 15TZ6 [TV Radio] ID = 1438220 933x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM FM Television Receiver 15TZ Series 15TZ6, Garod Radio Corp.; Brooklyn (NY):
SAMS Photofact Vol.4/49 498-12 Set 60 Folder 12

Country:  United States of America (USA)
Manufacturer / Brand:  Garod Radio Corp.; Brooklyn (NY)
Year: 1949 ? Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 33: 6J6 6J6 6J6 6BA6 6BA6 6BA6 6BA6 6AL5 6AC7 6SN7GT 6BA6 6AU6 6AU6 6T8 6K6GT 6SN7GT 6AR5 6SN7GT 6AL5 6SN7GT 6BG6G 5V4G 1B3GT 6BA6 12AT7 6BE6 5U4G 5Y3GT 6AT6 6V6GT 6V6GT 5Y3GT 15AP4 or 15CP4
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker 2 Loudspeakers / Ø 10 inch = 25.4 cm
Power out
from Radiomuseum.org Model: AM FM Television Receiver 15TZ Series 15TZ6 - Garod Radio Corp.; Brooklyn NY
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes

AM FM Television Receiver 15TZ6. Tuning ranges: AM 540 - 1650 kc, FM 88 - 108 Mc, TV channels 2 thru 13.

This set is equipped with a 15" picture tube, different types are possible. It also has a separate amplifier chassis with a push-pull configuration. There might be a third speaker present.

Mentioned in Photofact Folder, Howard W. SAMS (Date 4/49, Set 60, Folder 12 (498-12))
Literature/Schematics (1) Rider's TV, 3-1

Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.



All listed radios etc. from Garod Radio Corp.; Brooklyn (NY)
Here you find 377 models, 94 with images and 345 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
