Amplificatore Stereo-Radio FM MST6

Amplificatore Stereo-Radio FM MST6; GBC; Milano (ID = 658689) Radio
Amplificatore Stereo-Radio FM MST6; GBC; Milano (ID = 658686) Radio Amplificatore Stereo-Radio FM MST6; GBC; Milano (ID = 658687) Radio
Use red slider bar for more.
Amplificatore Stereo-Radio FM MST6; GBC; Milano (ID = 658686) Radio
GBC; Milano: Amplificatore Stereo-Radio FM MST6 [Radio] ID = 658686 933x345
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amplificatore Stereo-Radio FM MST6, GBC; Milano:
Selezione Radio-TV Ottobre /Novembre 1968

Country:  Italy
Manufacturer / Brand:  GBC; Milano
alternative name

Gian Bruto Castelfranchi
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 120/220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 80 W (unknown quality)
from Radiomuseum.org Model: Amplificatore Stereo-Radio FM MST6 - GBC; Milano
Material Wooden case
Shape Book-shelf unit.
Notes Amplificatore Stereo con sintonizzatore FM
Gamma di frequenza: 87-108 MHz
Potenza:40+40 Watt di picco su 8 OHm
Risposta di frequenza: 10-40000 Hz ± 2dB
Sensibilità: phono magnetico 1,3mV; ingressi ausiliari 150mV
Literature/Schematics (1) Selezione Radio-TV Ottobre /Novembre 1968

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
