WS88A MK2 Type A

WS88A MK2 Type A; Unknown - CUSTOM (ID = 887657) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 887658) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 887700) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888682) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888683) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888684) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888685) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888686) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888687) Military

WS88A MK2 Type A; Unknown - CUSTOM (ID = 888688) Military
WS88A MK2 Type A; Unknown - CUSTOM (ID = 1727161) Military WS88A MK2 Type A; Unknown - CUSTOM (ID = 887674) Military
WS88A MK2 Type A; Unknown - CUSTOM (ID = 887675) Military WS88A MK2 Type A; Unknown - CUSTOM (ID = 887676) Military
WS88A MK2 Type A; Unknown - CUSTOM (ID = 887673) Military WS88A MK2 Type A; Unknown - CUSTOM (ID = 887677) Military
WS88A MK2 Type A; Unknown - CUSTOM (ID = 887697) Military WS88A MK2 Type A; Unknown - CUSTOM (ID = 893002) Military
WS88A MK2 Type A; Unknown - CUSTOM (ID = 893003) Military WS88A MK2 Type A; Unknown - CUSTOM (ID = 893004) Military
Use red slider bar for more.
WS88A MK2 Type A; Unknown - CUSTOM (ID = 1727161) Military
Unknown - CUSTOM: WS88A MK2 Type A [Military] ID = 1727161 933x1099
Select picture or schematic to display from thumbnails on the right and click for download.
For model WS88A MK2 Type A, Unknown - CUSTOM BUILT: GB

Country:  Great Britain (UK)
Manufacturer / Brand:  Unknown - CUSTOM BUILT: GB
Year: 1947 ? Category: Military Equipment (not Re, Tr or RXT)
Valves / Tubes 13: 3A4 1T4 1L4 1L4 1L4 1L4 1L4 1T4 1T4 1T4 1A3 1A3 1S5
Main principle Transceiver; ZF/IF 3000 kHz; 1 AF stage(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Dry Batteries / 1,4 & 90 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: WS88A MK2 Type A - Unknown - CUSTOM BUILT: GB
Material Metal case
Shape Boatanchor (heavy military or commercial set).
Dimensions (WHD) 140 x 90 x 240 mm / 5.5 x 3.5 x 9.4 inch
Notes

Kleinfunksprechgerät der engl. Armee. 4Kanäle,A-42,15MHz; B-41,40MHz; C-40,90MHz; D-40,20MHz. Sender-Output ca 250mW FM.
Stromversorgung-Trockenbatterien Anode 90VDC. Heizung 1,4 VDC oder Akku mit Wechselrichter.

Also built under license by Standard Radio, Sweden, for Swedish Army, model Ra 130.

3000 built in Sweden from 1950. Additional 900 bought in 1958 from British Army.

Later rebuilt to Ra 130B (slightly different lineup with diodes as discriminator).



Net weight (2.2 lb = 1 kg) 2.650 kg / 5 lb 13.4 oz (5.837 lb)
Literature/Schematics (1) Bernd Jacobi-Surplushandbuch Band 1+2

Model page created by Rudolf Müller. See "Data change" for further contributors.
