Battery M.C.3 Receiver BC3436

GEC, General Electric Co Ltd., GENALEX; London

  • Year
  • 1933
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 191531
    • Brand: Gecophone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF with regeneration; 2 AF stage(s)
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 2 & 9 & 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Battery M.C.3 Receiver BC3436 - GEC, General Electric Co Ltd.,
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Jose Casas-Avalos. See "Data change" for further contributors.
