Centralino G1522C
 |
 |
 |
 |
 |
 |
 |
 |
Use red slider bar for more.
Geloso SA; Milano: Centralino G1522C [Radio] ID = 394978 933x542
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1959 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 7: ECC85 ECH81 EBF89 12AX7 6CA7 or EL34 12AX7 6CA7 or EL34 |
|---|
| Main principle | Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz |
|---|---|
| Wave bands | Broadcast, 2 Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 105-290 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | 25 W (unknown quality) |
| from Radiomuseum.org | Model: Centralino G1522C - Geloso SA; Milano |
| Material | Metal case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 516 x 266 x 260 mm / 20.3 x 10.5 x 10.2 inch |
| Notes | Il centralino è composto da: ricevitore AM-FM, amplificatore per un massimo di 20 altoparlanti con trasformatore di linea da 250 ohm, altoparlante di controllo diametro 10 cm, riproduzione fonografica in unione al mobiletto fonografico n. 1518. |
| Literature/Schematics (1) | Bollettino Tecnico Geloso (n. 75 estate 1959) |
Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
