G50R
Geloso SA; Milano
- Country
- Italy
- Manufacturer / Brand
- Geloso SA; Milano
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 95917
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 467 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19 cm = 7.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: G50R - Geloso SA; Milano
- Shape
- Miscellaneous shapes - described under notes.
- Notes
-
Il G50R poteva utilizzare i mobili nr 3040 (andamento orizzontale), nr 3011 (verticale) e 3706 (console con giradischi).
Utilizzando il gruppo Alta Frequenza Geloso AF1911A le gamme di frequenza erano Lunghe, Medie e Corte.
Con il gruppo AF Geloso 1912 A le gamme di frequenza erano Medie, Corte e Cortissime.
Controllo di tono.
- Source of data
- Guida Pratica Antique Radio III (2000)
- Mentioned in
- Guida Pratica Antique Radio II (2000)
- Literature/Schematics (1)
- -- Schematic (Schemario degli Apparecchi Radio D.E. Ravalico, V Edizione Hoepli 1954.)
