GTV1015

GTV1015; Geloso SA; Milano (ID = 1106807) Television

GTV1015; Geloso SA; Milano (ID = 1106808) Television
GTV1015; Geloso SA; Milano (ID = 314732) Television
Use red slider bar for more.
GTV1015; Geloso SA; Milano (ID = 314732) Television
Geloso SA; Milano: GTV1015 [Television] ID = 314732 579x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model GTV1015, Geloso SA; Milano:
From a Portuguese Prospect.

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1956–1958 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16:
Main principle Superheterodyne (common)
Details
Power type and voltage Alternating Current supply (AC) / 110-290 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: GTV1015 - Geloso SA; Milano
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 630 x 510 x 500 mm / 24.8 x 20.1 x 19.7 inch
Notes

21" CRT. Price in Portugal in 1958: 9990 PTE.

Prezzo 1957: 195,400.00 ITL

Price in first year of sale 190'000.00 ITL
Circuit diagram reference Schemario TV , Il Rostro
Mentioned in Bollettino Tecnico Geloso (n. 67, inverno 1957)
Literature/Schematics (1) L'antenna, n.10, ottobre 1956

Model page created by Alessandro De Poi. See "Data change" for further contributors.
