Lido 21MG110

Lido 21MG110; Geloso Argentina; (ID = 852375) Television Lido 21MG110; Geloso Argentina; (ID = 852385) Television
Lido 21MG110; Geloso Argentina; (ID = 852386) Television
Use red slider bar for more.
Lido 21MG110; Geloso Argentina; (ID = 852375) Television
Geloso Argentina;: Lido 21MG110 [Television] ID = 852375 914x808
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lido 21MG110, Geloso Argentina; Buenos Aires:
El boton de cambio de canales NO es original

Country:  Argentina
Manufacturer / Brand:  Geloso Argentina; Buenos Aires
Year: 1959 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 6BK7 6CG8 6CB6 6CB6 6CB6 6AU8 6U8 6AL5 6AQ5 6SN7 6SN7 6CY7 6DQ6 6AX4 1X2 21CEP4A
Main principle Superhet with RF-stage; ZF/IF 45750 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Lido 21MG110 - Geloso Argentina; Buenos Aires
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 580 x 510 x 380 mm / 22.8 x 20.1 x 15 inch
Notes Versión argentina del modelo GTV1018 de Geloso; Milano.
Source of data - - Data from my own collection

Model page created by Aldo Canepa. See "Data change" for further contributors.
