• Year
  • 1948/1949
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 181488

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz
  • Tuned circuits
  • 8 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 416 - General Motors of Canada;
  • Shape
  • Chassis only or for «building in»
  • Notes
  • Vibrator for +B.
  • Circuit diagram reference
  • Radio College of Canada
  • Literature/Schematics (1)
  • Canada schematics General Motors page 1 to 6
  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
