Capacitance bridge 1617

Capacitance bridge 1617; General Radio (ID = 322751) Equipment Capacitance bridge 1617; General Radio (ID = 322752) Equipment
Capacitance bridge 1617; General Radio (ID = 322753) Equipment
Use red slider bar for more.
Capacitance bridge 1617; General Radio (ID = 322751) Equipment
General Radio: Capacitance bridge 1617 [Equipment] ID = 322751 849x671
Select picture or schematic to display from thumbnails on the right and click for download.
For model Capacitance bridge 1617, General Radio Company; Cambridge (MA)

Country:  United States of America (USA)
Manufacturer / Brand:  General Radio Company; Cambridge (MA)
alternative name

GenRad
Year: 1964 ?? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Capacitance bridge 1617 - General Radio Company;
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 380 x 290 x 210 mm / 15 x 11.4 x 8.3 inch
Notes Measuring range 1 pF to 1000 µF. Internal generator 100 Hz.
Mentioned in - - Data from my own collection

Model page created by Pietro Gallia. See "Data change" for further contributors.
