Distortion and Noise Meter 1932-A

Distortion and Noise Meter 1932-A; General Radio (ID = 1836237) Equipment
Distortion and Noise Meter 1932-A; General Radio (ID = 1245496) Equipment Distortion and Noise Meter 1932-A; General Radio (ID = 1245497) Equipment
Distortion and Noise Meter 1932-A; General Radio (ID = 1245498) Equipment Distortion and Noise Meter 1932-A; General Radio (ID = 1245499) Equipment
Distortion and Noise Meter 1932-A; General Radio (ID = 1245500) Equipment Distortion and Noise Meter 1932-A; General Radio (ID = 1245505) Equipment
Distortion and Noise Meter 1932-A; General Radio (ID = 1245506) Equipment Distortion and Noise Meter 1932-A; General Radio (ID = 1245508) Equipment
Distortion and Noise Meter 1932-A; General Radio (ID = 1245510) Equipment Distortion and Noise Meter 1932-A; General Radio (ID = 1245511) Equipment
Use red slider bar for more.
Distortion and Noise Meter 1932-A; General Radio (ID = 1245496) Equipment
General Radio: Distortion and Noise Meter 1932-A [Equipment] ID = 1245496 933x501
Select picture or schematic to display from thumbnails on the right and click for download.
For model Distortion and Noise Meter 1932-A, General Radio Company; Cambridge (MA):
The General Radio Corp. from 'The General Radio Experimenter' Volume XXIV No. 1, June 1949.

Country:  United States of America (USA)
Manufacturer / Brand:  General Radio Company; Cambridge (MA)
alternative name

GenRad
Year: 1949 ? Category: Service- or Lab Equipment
Valves / Tubes 8: 6J5 6J5 6J5 6J5 6SN7GT 6K6GT 6H6 6X5 0D3 or VR150 0D3 or VR150
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105 - 125 or version for 210 - 250 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Distortion and Noise Meter 1932-A - General Radio Company;
Material Metal case
Shape Rack
Dimensions (WHD) 19 x 7 x 12 inch / 483 x 178 x 305 mm
Notes The General Radio Corp. Distortion and Noise Meter 1932-A is mentioned in "The General Radio Experimenter" Volume XXIV No. 1, June 1949. It is for instance used with theLow-Distortion Oscillator 1301-A. This combination will perform the measurements required in both FM and AM stations. It is available for either 105 to 125 volts or 210 to 250 volts.
Price in first year of sale 575.00 $

Model page created by Ernst Erb. See "Data change" for further contributors.
