For model GenRad 1687 Megahertz LC Digibridge, General Radio Company; Cambridge (MA):
Neues Foto soll erstes Bild ersetzen

Country:  United States of America (USA)
Manufacturer / Brand:  General Radio Company; Cambridge (MA)
alternative name

GenRad
Year: 1977 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle DSP, Digital Signal Processor
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 90-125 / 180-250 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: GenRad 1687 Megahertz LC Digibridge - General Radio Company;
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 375 x 343 x 112 mm / 14.8 x 13.5 x 4.4 inch
Notes

Very precise measuring bridge; working frequency 1MHz; measuring range 100nF, 100mH; 5 digit 7-segment LED display.

Sehr präzise Messbrücke, Arbeitsfrequenz 1MHz, Messbereich 100nF, 100mH, 5 Digit 7-Segment-LED-Anzeige.

Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)

Model page created by Horst Ostholt. See "Data change" for further contributors.
