Impedance-Measuring Circuit 821A

Impedance-Measuring Circuit 821A; General Radio (ID = 1244831) Equipment
Impedance-Measuring Circuit 821A; General Radio (ID = 1245270) Equipment Impedance-Measuring Circuit 821A; General Radio (ID = 1245268) Equipment
Use red slider bar for more.
Impedance-Measuring Circuit 821A; General Radio (ID = 1245270) Equipment
General Radio: Impedance-Measuring Circuit 821A [Equipment] ID = 1245270 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Impedance-Measuring Circuit 821A, General Radio Company; Cambridge (MA)

Country:  United States of America (USA)
Manufacturer / Brand:  General Radio Company; Cambridge (MA)
alternative name

GenRad
Year: 1955 Category: Service- or Lab Equipment
Wave bands Wave Bands given in the notes.
Details
Power type and voltage No Power needed
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Impedance-Measuring Circuit 821A - General Radio Company;
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 320 x 220 mm / 16.9 x 12.6 x 8.7 inch
Notes The Twin-T Impedance-Measuring Circuit is a null Instrument for use in measuring inpedance at frequencies from 460 kc to 30 Mc. Measurements can be made at frequencies slightly below and above this nominal frequency range.
Net weight (2.2 lb = 1 kg) 12.9 kg / 28 lb 6.6 oz (28.414 lb)
Price in first year of sale 570.00 $
Source of data -- Original-techn. papers.

Model page created by Alexander Küffer. See "Data change" for further contributors.
