• Country
• United States of America (USA)

• Manufacturer / Brand
• General Radio Company; Cambridge (MA)

• Year
• 1959–1965

• Category
• Power supply/conditioner or battery or charger

• Radiomuseum.org ID
• 170581

• • alternative name: GenRad

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• 12AT7 6AN8 6AV5 5651

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 210-250 Volt

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: Regulated Power Supply 1201-B - General Radio Company;

• Dimensions (WHD)
• 120 x 150 x 145 mm / 4.7 x 5.9 x 5.7 inch

• Notes
• To be used for powering a GENRAD Unit Oscillator (for instance Type 1208-B). Ouput: 300 V / 70 mA DC, regulated; 6,3 V / 4 A AC, unregulated.

• Source of data
• - - Data from my own collection

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Jean-Francois Loude. See "Data change" for further contributors.
