For model Unit Oscillator Type 1208-C, General Radio Company; Cambridge (MA):
GENERAL RADIO Unit Oscillator 1208-C

Country:  United States of America (USA)
Manufacturer / Brand:  General Radio Company; Cambridge (MA)
alternative name

GenRad
Year: 1965 ? Category: Service- or Lab Equipment
Valves / Tubes 1: 2C43
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / 320 & 6.3 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Unit Oscillator Type 1208-C - General Radio Company;
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 160 x 160 x 210 mm / 6.3 x 6.3 x 8.3 inch
Notes

Successor to the 1208-B, the 1208-C has a frequency operating range of 65 MHz to 500 MHz.

Output power: at least 200 mW into 50 ohms.

30% amplitude modulation is possible at audio frequency with an external source of 40 volts.

Power input: 320 VDC @ 40 mA and 6.3 VAC @ 900 mA via the 1269-A power supply.



Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)

Model page created by Georges Werts. See "Data change" for further contributors.
