Unit Power Supply 1203-B

Unit Power Supply 1203-B; General Radio (ID = 2241358) Power-S

Unit Power Supply 1203-B; General Radio (ID = 2241361) Power-S
Unit Power Supply 1203-B; General Radio (ID = 2241354) Power-S Unit Power Supply 1203-B; General Radio (ID = 2241355) Power-S
Unit Power Supply 1203-B; General Radio (ID = 2241356) Power-S Unit Power Supply 1203-B; General Radio (ID = 2241357) Power-S
Use red slider bar for more.
Unit Power Supply 1203-B; General Radio (ID = 2241354) Power-S
General Radio: Unit Power Supply 1203-B [Power-S] ID = 2241354 959x1000
Select picture or schematic to display from thumbnails on the right and click for download.
For model Unit Power Supply 1203-B, General Radio Company; Cambridge (MA):
One fuseholder has been replaced.

Country:  United States of America (USA)
Manufacturer / Brand:  General Radio Company; Cambridge (MA)
alternative name

GenRad
Year: 1962 ? Category: Power supply/conditioner or battery or charger
Valves / Tubes 1: 6X4
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Unit Power Supply 1203-B - General Radio Company;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 5 x 5.75 x 6.25 inch / 127 x 146 x 159 mm
Notes

General Radio model 1203B power supply. Outputs are 6.3Vac @ 3 A and 300 Vdc @ 50mA.

Net weight (2.2 lb = 1 kg) 5 lb (5 lb 0 oz) / 2.270 kg

Model page created by Jay Kinnard. See "Data change" for further contributors.
