For model BC5645, GEC, General Electric Co.; London:
My 1956 GEC BC5645 AC mains MW/LW/VHF 7 valve table radio in its dark brown bakelite case.

Country:  Great Britain (UK)
Manufacturer / Brand:  GEC, General Electric Co.; London
Brand

Gecophone
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: Z719 Z719 X719 W719 DH77 N709 U78
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: BC5645 - GEC, General Electric Co.;
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 17.5 x 11.75 x 8.5 inch / 445 x 298 x 216 mm
Notes Elliptical loudspeaker 8 x 5 inch.
Net weight (2.2 lb = 1 kg) 18 lb (18 lb 0 oz) / 8.172 kg
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader Sheet 1336

Model page created by Peter Hoddow. See "Data change" for further contributors.
