- Country
- Spain
- Manufacturer / Brand
- General Eléctrica Española (GEE); Madrid
- Year
- 1962 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 319087
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Valves / Tubes
- PCC189 PCF86 EF183 EF184 PCL84 PCF80 PCF80 EAA91 ECC82 PL36 PY88 DY87 PCL85 EAA91 PCL86 AW47-90
- Number of Transistors
- Main principle
- Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: 19H116 - General Eléctrica Española GEE
- Shape
- Tablemodel, low profile (big size).
- Notes
-
General Eléctrica Española (GEE), 19H116
TV B/N 19" con selector rotativo de VHF.
- Mentioned in
- Esquemario TV REDE, Tomo II, 1964
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
