Function Generator FG-8002

• Country
• South Korea

• Manufacturer / Brand
• Gold Star Co., Ltd., Goldstar, LG Electronics; Seoul

• Year
• 1990 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 309488

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Function Generator FG-8002 - Gold Star Co., Ltd., Goldstar,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 210 x 80 x 260 mm / 8.3 x 3.1 x 10.2 inch

• Notes

• Sweep function generator 0,02 Hz to 2 MHz in seven ranges.

  Output signals sine, square, sawtooth, DC and TTL.
