Super 12 3261

Super 12 3261; Gonset Inc., (ID = 326234) Amateur-D Super 12 3261; Gonset Inc., (ID = 326236) Amateur-D
Use red slider bar for more.
Super 12 3261; Gonset Inc., (ID = 326234) Amateur-D
Gonset Inc.,: Super 12 3261 [Amateur-D] ID = 326234 900x607
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super 12 3261, Gonset Inc., Waterproof Elect. Co.; Burbank (CA)

Country:  United States of America (USA)
Manufacturer / Brand:  Gonset Inc., Waterproof Elect. Co.; Burbank (CA)
Year: 1960 ?? Category: Amateur Equipment (Other, but not Key)
Valves / Tubes 3: 12EK6 12EK6 12EL6
Main principle RF Converter/Adapter (not voltage converter); ZF/IF 1430 kHz
Tuned circuits 2 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage and/or dry batteries / 12 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Super 12 3261 - Gonset Inc., Waterproof Elect.
Material Metal case
Notes Mobile converter for 75, 49, 40, 20, 19, 15, 11 and 10m band.
Source of data -- Original-techn. papers.

Model page created by Otto Frosinn. See "Data change" for further contributors.
