• Country
• United States of America (USA)

• Manufacturer / Brand
• Goodyear Tire & Rubber Co., Inc.; Akron, OH

• Year
• 1942 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 43340

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6K7 6C5 6C5 6K7 75 42 80

• Main principle
• Superhet with RF-stage; ZF/IF 465 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: 45-01005 Ch= Series A,B - Goodyear Tire & Rubber Co.,

• Notes
• Speaker 6 or 8 inch. In series B , the type 75 was replaced by type 6B7

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 13 = 1942 and before

• Literature/Schematics (1)
• Riders 13-1, 2

• Other Models

• Here you find 106 models, 16 with images and 90 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Goodyear Tire & Rubber Co., Inc.; Akron, OH
