FM-ZF-Verstärker 322-0005

FM-ZF-Verstärker 322-0005; Görler, J. K.; (ID = 1714194) mod-past25

FM-ZF-Verstärker 322-0005; Görler, J. K.; (ID = 1714195) mod-past25
Use red slider bar for more.
FM-ZF-Verstärker 322-0005; Görler, J. K.; (ID = 1714194) mod-past25
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl)
Year: 1964 ? Category: Radio module post 1925 (not a part, not a key)
Semiconductors (the count is only for transistors) 4: AF115 AF115 AF115 AF115
Main principle Radio Frequency Amplification only; ZF/IF 10700 kHz
Tuned circuits 8 FM circuit(s)
Details
Power type and voltage Powered by external power supply or a main unit. / 10 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: FM-ZF-Verstärker 322-0005 - Görler, J. K.; Berlin
Material Printed Circuit Board
Shape Chassis only or for «building in»
Dimensions (WHD) 130 x 50 x 24 mm / 5.1 x 2 x 0.9 inch
Notes

FM-ZF-Verstärker mit 4 diffusionslegierten Transistoren, Ratiodetektor.

Bandbreite:  300 kHz

Mentioned in -- Original-techn. papers.

Model page created by Manfred Rauschen. See "Data change" for further contributors.
