TR910

TR910; Görler, J. K.; (ID = 1954450) Radio

TR910; Görler, J. K.; (ID = 1954451) Radio

TR910; Görler, J. K.; (ID = 1954452) Radio

TR910; Görler, J. K.; (ID = 1954453) Radio

TR910; Görler, J. K.; (ID = 1954454) Radio

TR910; Görler, J. K.; (ID = 1954456) Radio

TR910; Görler, J. K.; (ID = 1954457) Radio

TR910; Görler, J. K.; (ID = 1954458) Radio

TR910; Görler, J. K.; (ID = 1954459) Radio

TR910; Görler, J. K.; (ID = 1954460) Radio
TR910; Görler, J. K.; (ID = 2290215) Radio TR910; Görler, J. K.; (ID = 2290217) Radio
TR910; Görler, J. K.; (ID = 381247) Radio
Use red slider bar for more.
TR910; Görler, J. K.; (ID = 2290215) Radio
Görler, J. K.;: TR910 [Radio] ID = 2290215 1256x406
Select picture or schematic to display from thumbnails on the right and click for download.
For model TR910, Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl):
ebay kleinanzeigen Nr. 918503029

Country:  Germany
Manufacturer / Brand:  Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl)
Year: 1973–1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 15:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 10 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: TR910 - Görler, J. K.; Berlin
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 440 x 120 x 280 mm / 17.3 x 4.7 x 11 inch
Notes ICs: 6.
HiFi-Stereo-Tuner.
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Price in first year of sale 700.00 DM
External source of data Erb
Source of data Katalog RFP 1973 / Radiokatalog Band 2, Ernst Erb
Mentioned in Handbuch VDRG 1974/1975 (und 1975/76)


All listed radios etc. from Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl)
Here you find 127 models, 101 with images and 113 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
