• Year
  • 1960 ??
  • Category
  • Miscellaneous (Other, Various) - see notes
  • Radiomuseum.org ID
  • 275822

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • No Power needed / 100-500 Volt
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: Gossen Drehfeldanzeige - Gossen, P., & Co. KG PGCD;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 70 x 98 x 30 mm / 2.8 x 3.9 x 1.2 inch
  • Notes
  • Anzeigegerät für Drehfeldrichtung, mobile Ausführung.

    3 Schraubanschlüsse für Testkabel an der Oberseite: R = Gelb, S = Grün, T = Lila

  • Net weight (2.2 lb = 1 kg)
  • 0.2 kg / 0 lb 7 oz (0.441 lb)
  • Author
  • Model page created by Gerhard Hoffmann. See "Data change" for further contributors.
