Konstanter T4 K16 B8

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640400) Equipment

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640401) Equipment

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640402) Equipment

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640403) Equipment

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640404) Equipment

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640405) Equipment

Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640406) Equipment
Use red slider bar for more.
Konstanter T4 K16 B8; Gossen, P., & Co. KG (ID = 1640400) Equipment
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Gossen, P., & Co. KG (PGCD); Erlangen, Nürnberg
Year: 1970 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 127-240 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: Konstanter T4 K16 B8 - Gossen, P., & Co. KG PGCD;
Dimensions (WHD) 245 x 200 x 270 mm / 9.6 x 7.9 x 10.6 inch
Notes

Transistorgeregeltes Niederspannungsgerät, wartungsfreie Gleichspannungsquelle hoher Konstanz, großer Leistung und niedrigen Innenwiderstandes für Prüf- und Meßschaltungen, elektronische Geräte.
Kenndaten:
Ausgangsspannung: 0 - 16 Volt, Ausgangsstrom: 8 Amp. (max.)

Net weight (2.2 lb = 1 kg) 9.8 kg / 21 lb 9.4 oz (21.586 lb)

Model page created by Hannes Gerber. See "Data change" for further contributors.
