Pantam Konstanter T4 33 2

Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 995990) Equipment

Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 995991) Equipment
Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 2472930) Equipment Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 2472931) Equipment
Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 297256) Equipment Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 297257) Equipment
Use red slider bar for more.
Pantam Konstanter T4 33 2; Gossen, P., & Co. KG (ID = 2472930) Equipment
Gossen, P., & Co. KG: Pantam Konstanter T4 33 2 [Equipment] ID = 2472930 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pantam Konstanter T4 33 2, Gossen, P., & Co. KG (PGCD); Erlangen, Nürnberg

Country:  Germany
Manufacturer / Brand:  Gossen, P., & Co. KG (PGCD); Erlangen, Nürnberg
Year: 1966 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Power Supply (not only Batt.El.)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Pantam Konstanter T4 33 2 - Gossen, P., & Co. KG PGCD;
Material Metal case
Shape Tablemodel, low profile (big size).
Notes Gleichspannungsnetzteil, 0 bis 33 V, Strombegrenzung von 20 mA bis 2 A stufenlos wählbar, Meßinstrument eingebaut.
Mentioned in Funkschau (1966 Heft 2 Seite 85)

Model page created by a member from A. See "Data change" for further contributors.
