Signal Generator D1/D

Signal Generator D1/D; Advance Instruments; (ID = 1889328) Equipment Signal Generator D1/D; Advance Instruments; (ID = 1889329) Equipment
Signal Generator D1/D; Advance Instruments; (ID = 1889330) Equipment Signal Generator D1/D; Advance Instruments; (ID = 1889331) Equipment
Signal Generator D1/D; Advance Instruments; (ID = 1889332) Equipment Signal Generator D1/D; Advance Instruments; (ID = 1889333) Equipment
Signal Generator D1/D; Advance Instruments; (ID = 1889334) Equipment Signal Generator D1/D; Advance Instruments; (ID = 1889335) Equipment
Use red slider bar for more.
Signal Generator D1/D; Advance Instruments; (ID = 1889328) Equipment
Advance Instruments;: Signal Generator D1/D [Equipment] ID = 1889328 1400x1004
Select picture or schematic to display from thumbnails on the right and click for download.
For model Signal Generator D1/D, Advance Instruments; Hainault Essex

Country:  Great Britain (UK)
Manufacturer / Brand:  Advance Instruments; Hainault Essex
alternative name

Advance Components Ltd.
Year: 1956 ? Category: Service- or Lab Equipment
Valves / Tubes 4: 6AF4 5Z4G 6J5GT 6J5GT
schematic requested
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 80; 110; 210; 230; 250 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Signal Generator D1/D - Advance Instruments; Hainault
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 340 x 310 x 16 mm / 13.4 x 12.2 x 0.6 inch
Notes

Game di frequenzia in MHz:
A 10/18 - B 18/32 - C 30/55 - D 55/105 - E 100/190 - F 170/300

Net weight (2.2 lb = 1 kg) 15.5 kg / 34 lb 2.3 oz (34.141 lb)

Model page created by Massimo Carli. See "Data change" for further contributors.
