Majestic 393 Ch= 390

Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 670672) Radio

Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 670673) Radio
Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 1659403) Radio Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 1659404) Radio
Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 933875) Radio Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 1130564) Radio
Use red slider bar for more.
Majestic 393 Ch= 390; Grigsby-Grunow - (ID = 1659403) Radio
Grigsby-Grunow -: Majestic 393 Ch= 390 [Radio] ID = 1659403 872x1400
Select picture or schematic to display from thumbnails on the right and click for download.
For model Majestic 393 Ch= 390, Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL):
Scanned from the Grigsby-Grunow Co. Folder for 1933 for Majestic Radios.

Country:  United States of America (USA)
Manufacturer / Brand:  Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL)
Year: 1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 58 56 58 58 55 56 53 80
Main principle Superhet with RF-stage; ZF/IF 175 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Majestic 393 Ch= 390 - Grigsby-Grunow -Hinds Co.
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 27.75 x 42 x 11.75 inch / 705 x 1067 x 298 mm
Notes

6 legged lowboy with stretcher base.
Push-pull af output stage.
Introduced Feb. 1933.

Price in first year of sale 69.50 $
Source of data Pre-War Consoles
Circuit diagram reference Rider's Perpetual, Volume 3 = 1933 and before
Literature/Schematics (3) The Grigsby-Grunow Co. Folder for 1933 for Majestic Radios.

Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
