Majestic 194 Ch= 440

Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 670094) Radio

Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 670095) Radio
Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 1531180) Radio Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 936201) Radio
Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 1659503) Radio Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 1659504) Radio
Use red slider bar for more.
Majestic 194 Ch= 440; Grigsby-Grunow - (ID = 1531180) Radio
Grigsby-Grunow -: Majestic 194 Ch= 440 [Radio] ID = 1531180 933x1324
Select picture or schematic to display from thumbnails on the right and click for download.
For model Majestic 194 Ch= 440, Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL):
Image courtesy of Mark V. Stein for Radiomuseum.org use only. From Machine Age to Jet Age, Volume 2.

Country:  United States of America (USA)
Manufacturer / Brand:  Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL)
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 6A7 6F7 41 6Z5
Main principle Super-Heterodyne (Super in general); ZF/IF 456 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Majestic 194 Ch= 440 - Grigsby-Grunow -Hinds Co.
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Dimensions (WHD) 9.625 x 13.25 x 6.625 inch / 244 x 337 x 168 mm
Notes

Introduced Sept. 1933

Price in first year of sale 19.95 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 4 = ca. 1934 and before
Mentioned in Machine Age to Jet Age II (page 189.)
Literature/Schematics (1) Cathedral & Tombstone Radios (page 170.)
Literature/Schematics (3) The Majestic Folder "Smart Set".
