Majestic 22 Ch= 20

Majestic 22 Ch= 20; Grigsby-Grunow - (ID = 678010) Radio

Majestic 22 Ch= 20; Grigsby-Grunow - (ID = 678011) Radio

Majestic 22 Ch= 20; Grigsby-Grunow - (ID = 678012) Radio
Use red slider bar for more.
Majestic 22 Ch= 20; Grigsby-Grunow - (ID = 678010) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL)
Year: 1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 51 27 51 51 27 45 45 80
Main principle Superhet with RF-stage; ZF/IF 175 kHz; Screengrid 1926-1935
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Majestic 22 Ch= 20 - Grigsby-Grunow -Hinds Co.
Notes Push-pull af output stage.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
