For model Majestic 461 Master Six Ch= 460, Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL):
Image courtesy of Mark V. Stein for Radiomuseum.org use only. From Machine Age to Jet Age, Volume 2.

Country:  United States of America (USA)
Manufacturer / Brand:  Grigsby-Grunow (-Hinds) Co. (Majestic pre 1933); Chicago (IL)
Year: 1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 58 2A7 58 55 2A5 80
Main principle Superhet with RF-stage; ZF/IF 175 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Majestic 461 Master Six Ch= 460 - Grigsby-Grunow -Hinds Co.
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 13.25 x 17 x 8.375 inch / 337 x 432 x 213 mm
Notes

Art Deco, Chrome Grille. Introduced June 1933.

Stein "Cathedral & Tombstone Radios" lists two bands for this model.

Price in first year of sale 32.50 $
External source of data Ernst Erb
Source of data A Blast from the Past
Circuit diagram reference Rider's Perpetual, Volume 4 = ca. 1934 and before
Mentioned in Table Top Radios Vol. 1 Stein 98
Literature/Schematics (1) Collector's Guide to Antique Radios (6th edition)
Literature/Schematics (2) Machine Age to Jet Age II
Literature/Schematics (3) Cathedral & Tombstone Radios (page 172.)
Literature/Schematics (4) The Majestic Folder "Smart Set".
