10 PG ; Grommes Precision (ID = 2486674) Ampl/Mixer
Grommes Precision: 10 PG [Ampl/Mixer] ID = 2486674 1400x965
Select picture or schematic to display from thumbnails on the right and click for download.
For model 10 PG, Grommes Precision Electronics, Inc.; Chicago (IL):
Picture from service manual.

Country:  United States of America (USA)
Manufacturer / Brand:  Grommes Precision Electronics, Inc.; Chicago (IL)
Year: 1957 ? Category: Audio Amplifier or -mixer
Valves / Tubes 6: 12AX7 12AX7 12AX7 6V6GT 6V6GT 5Y3GT
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker - This model requires external speaker(s).
Power out 75 W (undistorted)
from Radiomuseum.org Model: 10 PG - Grommes Precision Electronics,
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 300 x 165 x 230 mm / 11.8 x 6.5 x 9.1 inch
Notes

Grommes model 10PG is an AC operated 6 channel 10 watt audio amplifier.

Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 381, folder 9 dated 12-57)

Model page created by Michael Gnaedig-Fischer. See "Data change" for further contributors.
