• Country
• United States of America (USA)

• Manufacturer / Brand
• Grommes Precision Electronics, Inc.; Chicago (IL)

• Year
• 1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 244033

• Number of Tubes
• 9

• Valves / Tubes
• 6DT8 6DT8 6HS6 6HS6 6HS6 6FG6 6C4 12AU7 6EU7

• Main principle
• Superhet with RF-stage

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: FM Tuner 101 B - Grommes Precision Electronics,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 14 x 4.5 x 11.5 inch / 356 x 114 x 292 mm

• Notes

• FM multiplex stereo tuner.

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.

• Other Models

• Here you find 73 models, 66 with images and 49 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
