Alltransistor RF3301 Ch= CS150

Alltransistor RF3301 Ch= CS150; Grundig Radio- (ID = 1081301) Radio Alltransistor RF3301 Ch= CS150; Grundig Radio- (ID = 1081302) Radio
Alltransistor RF3301 Ch= CS150; Grundig Radio- (ID = 1081303) Radio Alltransistor RF3301 Ch= CS150; Grundig Radio- (ID = 1081304) Radio
Alltransistor RF3301 Ch= CS150; Grundig Radio- (ID = 1081305) Radio
Use red slider bar for more.
Alltransistor RF3301 Ch= CS150; Grundig Radio- (ID = 1081301) Radio
Grundig Radio-: Alltransistor RF3301 Ch= CS150 [Radio] ID = 1081301 933x405
Select picture or schematic to display from thumbnails on the right and click for download.
For model Alltransistor RF3301 Ch= CS150, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1970 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: BF185 BF185 BF194 BF195 BF238 BF237 BC148 BC181 AC117 AC187 AC188
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Alltransistor RF3301 Ch= CS150 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 650 x 155 x 195 mm / 25.6 x 6.1 x 7.7 inch
Notes Der Empfänger RF3301 basiert auf dem Chassis der Modelle RF150 und RF152, hat jedoch eine zusätzliche Skalenbeleuchtung (6V; 0,05A)für die Feldstärkeanzeige sowie eine Außenlautsprecheranschlußbuchse.
Net weight (2.2 lb = 1 kg) 5.4 kg / 11 lb 14.3 oz (11.894 lb)
Source of data - - Data from my own collection

Model page created by Klaus-Hartwig Müller. See "Data change" for further contributors.
