C10 Automatic

C10 Automatic; Grundig Radio- (ID = 673826) R-Player

C10 Automatic; Grundig Radio- (ID = 673827) R-Player

C10 Automatic; Grundig Radio- (ID = 673828) R-Player

C10 Automatic; Grundig Radio- (ID = 673829) R-Player

C10 Automatic; Grundig Radio- (ID = 673832) R-Player

C10 Automatic; Grundig Radio- (ID = 710986) R-Player

C10 Automatic; Grundig Radio- (ID = 710988) R-Player

C10 Automatic; Grundig Radio- (ID = 710989) R-Player
C10 Automatic; Grundig Radio- (ID = 1097206) R-Player C10 Automatic; Grundig Radio- (ID = 53066) R-Player
C10 Automatic; Grundig Radio- (ID = 710973) R-Player C10 Automatic; Grundig Radio- (ID = 1097228) R-Player
Use red slider bar for more.
C10 Automatic; Grundig Radio- (ID = 1097206) R-Player
Grundig Radio-: C10 Automatic [R-Player] ID = 1097206 933x541
Select picture or schematic to display from thumbnails on the right and click for download.
For model C10 Automatic, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Q: Grundig, Produkt-Katalog 1971

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1971/1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / 6×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: C10 Automatic - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 220 x 70 x 255 mm / 8.7 x 2.8 x 10 inch
Notes Grundig Cassetten-Recorder C10 Automatic.
Übertragungsbereich: 150···8000 Hz.
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Price in first year of sale 138.00 DM
External source of data Erb
Source of data Handbuch VDRG 1971/1972
