BK200; Grundig Radio- (ID = 617765) R-Player
Grundig Radio-: BK200 [R-Player] ID = 617765 450x377
Select picture or schematic to display from thumbnails on the right and click for download.
For model BK200, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Quelle: ebay 180356990300.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1967 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Video-Taperecorder/-Player
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: BK200 - Grundig Radio-Vertrieb, RVF,
Material Various materials
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 650 x 260 x 340 mm / 25.6 x 10.2 x 13.4 inch
Notes

Video Signal Systems (Playback): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_]
Video Signal Systems (Record): CCIR PAL: [X] SECAM: [_] [_] NTSC: [_] other: [_]
Videostandard: 2" Quadruplex: [_] 1"-A: [_] 1"-B: [_] 1"-C: [_] LDL: [_] VCR Standard: [_] VCR-Longplay: [_] SVR: [_] U-Matic Lowband: [_] U-Matic Highband: [_] U-Matic SP: [_] Betamax: [_] Betacam SP: [_] Video2000: [_] Video 8:[_] High 8: [_] VHS: [_] S-VHS: [_] other: [X]
Tuner equipped: [N];  HF Output: [N];  Timer: [N];   Color: [optional];  Insert-Cut: [N];
Controlable by Editing-System: [N];  Output Level: [ 1 V ];  RGB video output: [N]
Composite (FBAS) Video Output: [Y]; Component Video Output: [N]
S-Video output: [N]
Non-symmetrical Audio Out (RCA/cinch Connector): [Y]
Symmetrical Audio Out (XLR/cannon Connector): [Y];  Timebase Corrector: [No]
Remote Control: [by wire]

No. of rotating Videoheads: 2;  No. of Audiochannels linear track: 2
No. of Audiochannels helical track: 0;  Horizontal Resolution black/white: 400 lines
Horizontal Resolution Color: ?;  Signal to Noise Video: >50 dB
Signal to Noise linear Audio track: 40 dB;  Signal to Noise helical Audio track: __ dB;
Audio Frequency Response: 60 HZ to 12500 Hz;   Wow and Flutter: 0.15%



Grundig BK 200:
Semi-professioneller Videorecorder nach CCIR mit offenen 1" Spulen übereinander angeordnet, 4 Asynchronmotoren, 75 min Aufnahmezeit, 21cm/s Bandgeschwindigkeit, 5 MHz/400 Zeilen Auflösung, Umspulzeit max. 3,5 Minuten bei voller 10,5 Zoll Spule. verschiedene Ausstattungen. Komplette Beschreibung mit allen Schaltungen (auch der Fernbedienung) in: Grundig, Technische Informationen 2/1971.

Als Sonderzubehör waren u. A. ein Farb Nachrüstsatz und ein Fernbedienpult erhältlich. Es können mehrere Fernbedienung gleichzeitig angeschlossen werden, so daß der Rekorder von verschiedenen Plätzen bedienbar ist. Die Bandzählwerke aller Fernbedienpulte laufen synchron zum Zählwerk des Rekorders.

Net weight (2.2 lb = 1 kg) 48 kg / 105 lb 11.6 oz (105.727 lb)
Price in first year of sale 15'000.00 DM
Mentioned in Funkschau (Heft 19, 1967 & Grundig - Technische Informationen 3/1970 mit Teil I)
