For model Boy 40a, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Grundig Boy 40a

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1989 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Storage and/or dry batteries / AA: 2 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 0.3 W (max.)
from Radiomuseum.org Model: Boy 40a - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 150 x 90 x 27 mm / 5.9 x 3.5 x 1.1 inch
Notes

Teleskopantenne 40 cm, Ferritantenne 5,5 cm, Kopfhöreranschluß über 3,5 mm Klinkenbuchse. Made by Grundig in Malaysia. Batterien vom Typ "Mignon".

Siehe auch Grundig Boy 40L mit LW und UKW.

Net weight (2.2 lb = 1 kg) 0.265 kg / 0 lb 9.3 oz (0.584 lb)
Price in first year of sale 36.40 DM

Model page created by Herbert Odermatt † 26.Nov.05. See "Data change" for further contributors.
