For model C2800 Automatic KW - Ausführung, Grundig (Radio-Vertrieb, RVF, Radiowerke):
C 2800 Automatik

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1976–1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 19:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 120-127; 220-230 / 5×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.7 W (unknown quality)
from Radiomuseum.org Model: C2800 Automatic [KW - Ausführung] - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 170 x 64 mm / 12.4 x 6.7 x 2.5 inch
Notes

Grundig Radio-Recorder C2800 Automatic.
Eingebautes Elektret-Kondensator-Mikrofon; Übertragungsbereich: 80-10000 Hz.

Weitere Unterlagen beim C2600KW

Net weight (2.2 lb = 1 kg) 2.285 kg / 5 lb 0.5 oz (5.033 lb)
Source of data Handbuch VDRG 1977/1978
Mentioned in Handbuch VDRG 1976/1977
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Werner Kassenbrock. See "Data change" for further contributors.
