CD Player CDP80
Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke); Fürth/Bayern
- Year
- 1993 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 203570
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Bild aus Grundig Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- CD-Player, -Writer, MD, MOD (audio)
- Power type and voltage
- Batteries / addl. power jack / 2x 1,5 / 3 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Various materials
- from Radiomuseum.org
- Model: CD Player CDP80 - Grundig Radio-Vertrieb, RVF,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Notes
- CD Player; Stromversorgung 2x UM 3 mit je 1,5 Volt, oder Netzteil mit 3 Volt.
- Mentioned in
- Original Grundig Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
