CD Radio Recorder RRCD 1300

CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713006) Radio CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713007) Radio
CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713008) Radio CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713009) Radio
CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713010) Radio CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713011) Radio
CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713012) Radio
Use red slider bar for more.
CD Radio Recorder RRCD 1300; Grundig Radio- (ID = 1713006) Radio
Grundig Radio-: CD Radio Recorder RRCD 1300 [Radio] ID = 1713006 933x656
Select picture or schematic to display from thumbnails on the right and click for download.
For model CD Radio Recorder RRCD 1300, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 2005 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details Other Combination - see Notes
Power type and voltage Line / Batteries (any type) / 230 / 6 x 1,5 Volt
Loudspeaker 2 Loudspeakers
Power out 3 W (6 W max.)
from Radiomuseum.org Model: CD Radio Recorder RRCD 1300 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 400 x 143 x 230 mm / 15.7 x 5.6 x 9.1 inch
Notes

Grundig RRCD 1300

CD-Radio-Recorder mit CD-Player, der auch CD-Rs/CD-RWs im CD-DA-Format abspielen kann

- 20 Titelspeicher

- Ultra Bass System

- Stereo-Kopfhörer-Anschluß

- kein Auto-Reverse.

Net weight (2.2 lb = 1 kg) 2.8 kg / 6 lb 2.7 oz (6.167 lb)

Model page created by Jörg Holtzapfel. See "Data change" for further contributors.
