• Year
  • 1979
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 172987
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 39
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 120-127; 220-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: CN510 HIFI - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 220 x 80 x 240 mm / 8.7 x 3.1 x 9.4 inch
  • Notes
  • HiFi-Stereo-Cassetten-Deck
    2 Ausführungen: schwarz und alufärbig
    Frequenzumfang: 40···12500 Hz
    Dolby-NR.
  • Net weight (2.2 lb = 1 kg)
  • 2.1 kg / 4 lb 10 oz (4.626 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Grundig Technische Informationen 1/1979)
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
