Color electronic T 902

Color electronic T 902; Grundig Radio- (ID = 2069665) Television

Color electronic T 902; Grundig Radio- (ID = 2069667) Television

Color electronic T 902; Grundig Radio- (ID = 2069668) Television

Color electronic T 902; Grundig Radio- (ID = 2069669) Television

Color electronic T 902; Grundig Radio- (ID = 2069670) Television

Color electronic T 902; Grundig Radio- (ID = 2069672) Television

Color electronic T 902; Grundig Radio- (ID = 2069674) Television

Color electronic T 902; Grundig Radio- (ID = 2069675) Television

Color electronic T 902; Grundig Radio- (ID = 2069676) Television

Color electronic T 902; Grundig Radio- (ID = 2069677) Television
Use red slider bar for more.
Color electronic T 902; Grundig Radio- (ID = 2069665) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1969/1970 Category: Television Receiver (TV) or Monitor
Valves / Tubes 5: PCL805 PCF802 PL509 PY88 A56-120X
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Color electronic T 902 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 680 x 470 x 505 mm / 26.8 x 18.5 x 19.9 inch
Notes

Grundig T 902 Color electronic mit VHF/UHF Allbereich Tuner mit Dioden-Abstimmung. VHF UHF Drucktasten. 9 Drucktasten 7 VHF/UHF Programmtasten, Sprache/Musik, Ein/AUS. Fernbedienung VII Color (Lautstärke, Helligkeit, Farbkontrast). Gehäuse Edelholz, mitteldunkel poliert oder hell mattiert

Net weight (2.2 lb = 1 kg) 38 kg / 83 lb 11.2 oz (83.7 lb)
Price in first year of sale 2'048.00 DM
Mentioned in Handbuch VDRG 1969/1970
Literature/Schematics (2) -- Original-techn. papers.

Model page created by Josef Pilz. See "Data change" for further contributors.
