Como 3 Ch= CS160MS

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644018) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644019) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644020) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644021) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644022) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644023) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644024) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644025) Radio

Como 3 Ch= CS160MS; Grundig Radio- (ID = 644026) Radio
Como 3 Ch= CS160MS; Grundig Radio- (ID = 1523358) Radio Como 3 Ch= CS160MS; Grundig Radio- (ID = 1523353) Radio
Como 3 Ch= CS160MS; Grundig Radio- (ID = 1546758) Radio
Use red slider bar for more.
Como 3 Ch= CS160MS; Grundig Radio- (ID = 1523358) Radio
Grundig Radio-: Como 3 Ch= CS160MS [Radio] ID = 1523358 933x1043
Select picture or schematic to display from thumbnails on the right and click for download.
For model Como 3 Ch= CS160MS, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Bild von Grundig Betriebsanleitung

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1969/1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21: BF222 or. BF314 BF185 or. BF255 BF195 BF194 BF238 BF237 BC149 or. BC239 BC149 or. BC239 BC181 BC181 AC187 AC188 AC187 AC188 AD162
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 8 W (unknown quality)
from Radiomuseum.org Model: Como 3 Ch= CS160MS - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 780 x 820 x 360 mm / 30.7 x 32.3 x 14.2 inch
Notes Como3 basiert auf dem Chassis CS160MS und ist die Kombination eines Stereo- Radios mit einem Plattenspieler. Phono-Chassis = Dual Automatic 36.
Mit oder ohne Stereo Decoder 10.
Mentioned in - - Manufacturers Literature

Model page created by Bland Schwarting. See "Data change" for further contributors.
