Concert-Boy 206

Concert-Boy 206; Grundig Radio- (ID = 94306) Radio

Concert-Boy 206; Grundig Radio- (ID = 94307) Radio

Concert-Boy 206; Grundig Radio- (ID = 94308) Radio

Concert-Boy 206; Grundig Radio- (ID = 94309) Radio

Concert-Boy 206; Grundig Radio- (ID = 94310) Radio

Concert-Boy 206; Grundig Radio- (ID = 2001903) Radio

Concert-Boy 206; Grundig Radio- (ID = 2001904) Radio
Concert-Boy 206; Grundig Radio- (ID = 1681680) Radio Concert-Boy 206; Grundig Radio- (ID = 189390) Radio
Concert-Boy 206; Grundig Radio- (ID = 189391) Radio Concert-Boy 206; Grundig Radio- (ID = 615584) Radio
Concert-Boy 206; Grundig Radio- (ID = 249409) Radio Concert-Boy 206; Grundig Radio- (ID = 283471) Radio
Concert-Boy 206; Grundig Radio- (ID = 283473) Radio Concert-Boy 206; Grundig Radio- (ID = 283474) Radio
Concert-Boy 206; Grundig Radio- (ID = 283476) Radio Concert-Boy 206; Grundig Radio- (ID = 472628) Radio
Use red slider bar for more.
Concert-Boy 206; Grundig Radio- (ID = 1681680) Radio
Grundig Radio-: Concert-Boy 206 [Radio] ID = 1681680 803x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model Concert-Boy 206, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 13: AF106 AF106 AF126 AF126 AF126 AF126 AF121 BC108B BC108B BC108B AC117 AC175 AD156
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Concert-Boy 206 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 360 x 210 x 110 mm / 14.2 x 8.3 x 4.3 inch
Notes

Betrieb im Auto über Autobatteriekabel aus 6-V- oder 12-V-Autobatterie möglich. Netzbetrieb mit einsetzbarem oder extern anschließbarem Netzteil möglich.

Siehe auch Exportversion Transistor 1000.

Net weight (2.2 lb = 1 kg) 4.1 kg / 9 lb 0.5 oz (9.031 lb)
Source of data Handbuch VDRG 1966/1967 / Radiokatalog Band 1, Ernst Erb
