Cosmopolit G.DZ76; Grundig Radio- (ID = 498027) Radio
Grundig Radio-: Cosmopolit G.DZ76 [Radio] ID = 498027 933x534
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cosmopolit G.DZ76, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Original prospekt in 1992!

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1989–1992 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 34:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Dry Batteries / 3 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Cosmopolit G.DZ76 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 200 x 92 x 43 mm / 7.9 x 3.6 x 1.7 inch
Notes Eingebaute Digitaluhr mit Sprachausgabe und Weckfunktion.
7 Kurzwellenbänder: 49 m, 41 m, 31 m, 25 m, 22 m, 19 m, 16 m.
Stereowiedergabe (auch UKW) ist über Kopfhörer möglich. 3V-Lithiumbatterie für die Uhr: CR 2016.
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Source of data -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
